FW series
The FW-391 is our P3.91 (500 x 500mm) LED video panel that is a cost-effective, high-performance solution looking for crystal clear resolution with a range of dynamic flexibility. A 3.91mm pixel pitch that uses high-performance, flicker-free LEDs deliver HD clarity in a wide range of touring and permanent install applications.
Lightweight Touring: Reduce weight load and shipping costs with die-castingaluminum LED panels. Save setup and labor time withdynamic deployment options.
Indoor & Outdoor: A LED display solution with curated LEDs is suitable forindoor and outdoor environments without compromisingimage quality at all brightness levels. Vivid visibility in lightor dim environments with IP65-rated protection. Ultra-highbrightness options are available.
1. HIGH PERFORMANCE HDR TECHNOLOGY
Top-notch visual performance.Forwnin panels are built around the NovaStar™ A8s receiver card, offering HDR10 and HLG support, automatic module calibration, image rotation, and an advanced 3-in-1 SMD LED configuration.High-performance LED video display systems can assist rental companies and production providers in delivering advanced LED display solutions in any setting. These solutions meet and surpass the demanding requirements of high-profile key events, enabling them to gain a competitive edge.
2. DIRECT MODULE CONNECTION
With direct module connection and a best-in-class design, FW series LED screens offer not only seamless installation but also exceptional reliability, providing a visually stunning and dependable display solution for a wide range of applications. Ribbon-cable-free designs for enhanced stability. Modularcomponents for easy field serviceability and minimal downtime.
3. RUGGED CABINET, FRONT AND REAR SERVICEABILITY
Rugged cabinets made with an integrated molding process are designed to be portable and expandable, with indoor and outdoor options to suit any active application in any harsh environment. Front and rear serviceable LED panels offer multiple deployment options, ensuring labor efficiency and flexibility to accommodate a range of stage and set designs.
4. FULL-SCALE FLEXIBILITY
Rigging hardware for flying and ground stackingintegrated into a lightweight frame for quick deploymentwith standard concave/convex curving expanding design flexibility.
| Panel Name: | FW series |
| Pixel Configuration: | NationStar |
| Pixel Pitch: | 3.91mm |
| Resolution: | 128 x 128mm |
| Pixel Density: | 16,384 Pixels/㎡ |
| LED Tile Quantity: | 4pcs/panel (2 x 2) |
| Material: | Die-casting Aluminum |
| Dimensions: | 19.69 x 19.69 x 2.83" (500 x 500 x 72 mm) |
| Weight: | 14 lbs (6.6 kg) |
| Application: | Indoor / Outdoor |
| Receiving Card: | NovaStar |
| Brightness: | 1,000 nits / 4,500 nits |
| Refresh Rate: | ≥3840hz |
| Color Depth: | 16 bit |
| Scan Mode: | 1/16 |
| Optimal Viewing Distance: | 13 ~ 131 ft (4.0 ~ 40.0 m) |
| View Angle: | Horizontal 140°/ Vertical 140° |
| Input Voltage: | 100 ~ 240V AC |
| Frame Frequency: | 50/60Hz |
| Avg. Power Consumption: | 75 / 80W/Panel |
| Max. Power Consumption: | 170 / 190W/Panel |
| Maintenance Type: | Front / Rear |
| Lifespan: | 100,000 Hours |
| IP Rating: | IP43 (Indoor) / IP65 (Outdoor) |
| Warranty: | 2years |
1. HIGH PERFORMANCE HDR TECHNOLOGY
Top-notch visual performance.Forwnin panels are built around the NovaStar™ A8s receiver card, offering HDR10 and HLG support, automatic module calibration, image rotation, and an advanced 3-in-1 SMD LED configuration.High-performance LED video display systems can assist rental companies and production providers in delivering advanced LED display solutions in any setting. These solutions meet and surpass the demanding requirements of high-profile key events, enabling them to gain a competitive edge.
2. DIRECT MODULE CONNECTION
With direct module connection and a best-in-class design, FW series LED screens offer not only seamless installation but also exceptional reliability, providing a visually stunning and dependable display solution for a wide range of applications. Ribbon-cable-free designs for enhanced stability. Modularcomponents for easy field serviceability and minimal downtime.
3. RUGGED CABINET, FRONT AND REAR SERVICEABILITY
Rugged cabinets made with an integrated molding process are designed to be portable and expandable, with indoor and outdoor options to suit any active application in any harsh environment. Front and rear serviceable LED panels offer multiple deployment options, ensuring labor efficiency and flexibility to accommodate a range of stage and set designs.
4. FULL-SCALE FLEXIBILITY
Rigging hardware for flying and ground stackingintegrated into a lightweight frame for quick deploymentwith standard concave/convex curving expanding design flexibility.
| Panel Name: | FW series |
| Pixel Configuration: | NationStar |
| Pixel Pitch: | 3.91mm |
| Resolution: | 128 x 128mm |
| Pixel Density: | 16,384 Pixels/㎡ |
| LED Tile Quantity: | 4pcs/panel (2 x 2) |
| Material: | Die-casting Aluminum |
| Dimensions: | 19.69 x 19.69 x 2.83" (500 x 500 x 72 mm) |
| Weight: | 14 lbs (6.6 kg) |
| Application: | Indoor / Outdoor |
| Receiving Card: | NovaStar |
| Brightness: | 1,000 nits / 4,500 nits |
| Refresh Rate: | ≥3840hz |
| Color Depth: | 16 bit |
| Scan Mode: | 1/16 |
| Optimal Viewing Distance: | 13 ~ 131 ft (4.0 ~ 40.0 m) |
| View Angle: | Horizontal 140°/ Vertical 140° |
| Input Voltage: | 100 ~ 240V AC |
| Frame Frequency: | 50/60Hz |
| Avg. Power Consumption: | 75 / 80W/Panel |
| Max. Power Consumption: | 170 / 190W/Panel |
| Maintenance Type: | Front / Rear |
| Lifespan: | 100,000 Hours |
| IP Rating: | IP43 (Indoor) / IP65 (Outdoor) |
| Warranty: | 2years |
STELLAR VISUAL PERFORMANCE
Built around NovaStar™ A8s receiving cards, Forwnin panels offer HDR10 & HLG support, automatic module calibration, image rotation, and an advanced 3-in-1 SMD LED configuration.
High-performance LED video display systems can help rental houses and production providers gain a competitive advantage by offering advanced LED display solutions that meet and exceed the challenging requirements of high-profile, critical events in any environment.
Built around NovaStar™ A8s receiving cards, Forwnin panels offer HDR10 & HLG support, automatic module calibration, image rotation, and an advanced 3-in-1 SMD LED configuration.
High-performance LED video display systems can help rental houses and production providers gain a competitive advantage by offering advanced LED display solutions that meet and exceed the challenging requirements of high-profile, critical events in any environment.
MUSCLE AND FLEXIBILITY
Robust cabinets from integrated-formed processes are designed to be portable and scalable with indoor and outdoor options to accommodate any event application in any rugged environment. A front and rear serviceable LED panel can offer multiple deployment options that ensure labor efficiency and flexibility to accommodate an array of stage and set designs.
Robust cabinets from integrated-formed processes are designed to be portable and scalable with indoor and outdoor options to accommodate any event application in any rugged environment. A front and rear serviceable LED panel can offer multiple deployment options that ensure labor efficiency and flexibility to accommodate an array of stage and set designs.
